01. FRAME     eBIG.TOUR LITE IV; MAT aluminium; 29x2.35" without fender max./ 29"x2.25" with fender max. WHS; 148x12 AST; intube
02. SIZES     S-M-L-XL
03. FORK     Suntour XCM34-Boost LOR DS; 100mm; Tapered; 51mm fork offset; 29x2.4" max WHS
04. DRIVE UNIT     Shimano EP6; 85Nm
05. BATTERY     Shimano EN806; 630Wh
06. BATTERY CHARGER     Shimano EC-E6002; 2A charging current
07. DISPLAY     Shimano SC-EN500
08. REAR DERAILLEUR     Shimano CUES U6000 ; GS
09. SHIFTERS     Shimano CUES U6000
10. BRAKE - FRONT     Shimano MT-200; 2 piston
11. BRAKE - REAR     Shimano MT-200; 2 piston
12. ROTOR - FRONT     Shimano RT30; 180 mm
13. ROTOR - REAR     Shimano RTEM300; 180 mm
14. CHAINWHEEL     Shimano CRE70-B; 34 ATC
15. CRANK/SIZE     Shimano FC-EM600; 165mm
16. CHAIN     Shimano LG500
17. CASSETTE     Shimano LG300; 11-48 ATC; 10 GER
18. PEDALS     VP VPE-537
19. HANDLEBAR     MERIDA EXPERT CC; MAT aluminium; 720 WHB; 10 RHB
20. HANDLEBAR STEM     MERIDA EXPERT CT; MAT aluminium; 31.8 DSH; adjustable
21. STEM LENGTH     90 mm all sizes
22. SEAT POST     MERIDA EXPERT CC; MAT aluminium; 34.9 DSP; 0 SSB
23. SADDLE     MERIDA EXPERT TK; V-mount
24. HUB - FRONT     Shimano TC500-B; 110x15 WHF; 32 SPH; Centerlock
25. HUB - REAR     Shimano TC500-HM-B; 148x12 WHR; 36 SPH; Centerlock
26. AXLE - REAR     MERIDA EXPERT TR; including removeable lever, 6/4mm allen key
27. RIMS     MERIDA COMP CC II; 25 IWR; MAT aluminium
28. TYRES     KENDA Booster; 29x2.2"; wire
29. FENDERS     Sunnywheel SW-FA311-65A/ SW-FA311-65E1
30. CARRIER     MERIDA MA008-1 w/spring clamp Spanninga GLOW XE
31. KICKSTAND     CL-KA98, 29"
32. LIGHT-FRONT     LEZYNE E-BIKE HECTO STVZO E65
33. LIGHT-REAR     Spanninga Commuter GLOW XE
34. MAX RIDER WEIGHT     140kg
